NS16.039.00 Leaf Spring for Iveco EuroTrakker
Description
NS16.039.00 Leaf Spring for Iveco EuroTrakker
Available
Min. 50 pcs
Lead time 90 days
Placement
Rear
Type
Parabolic
Length (mm)
730-730
Section (mm)
100*3/26+1/43+1/10
Arc height (mm)
78
Weight (kg)
108.9600
Max Load (tons)
Comment
67177000
| Part No | Comment | Type | Weight (kg) | Length (mm) | Section (mm) | Price | |
|---|---|---|---|---|---|---|---|
| 67177001 | Parabolic | 26.4000 | 730-730 | 100*26 |
Available
|
$36.43
|
|
| 67177002 | Parabolic | 26.4000 | 730-730 | 100*26 |
Available
|
$36.43
|
|
| 67177003 | Parabolic | 26.4000 | 730-730 | 100*26 |
Available
|
$36.43
|
|
| 67177004 | Parabolic | 26.8000 | 550-550 | 100*43 |
Available
|
$42.53
|
|
| 67177005 | Conventional | 2.8000 | 180-180 | 100*10 |
Available
|
$3.86
|
Comment
67177001
Length (mm)
730-730
Type
Parabolic
Section (mm)
Weight (kg)
26.4000
Comment
67177002
Length (mm)
730-730
Type
Parabolic
Section (mm)
Weight (kg)
26.4000
Comment
67177003
Length (mm)
730-730
Type
Parabolic
Section (mm)
Weight (kg)
26.4000
Comment
67177004
Length (mm)
550-550
Type
Parabolic
Section (mm)
Weight (kg)
26.8000
Comment
67177005
Length (mm)
180-180
Type
Conventional
Section (mm)
Weight (kg)
2.8000
| Number | Brand | Number | Brand |
|---|---|---|---|
| 67177000 | Schomaecker | F061T254ZA70 | Weweler |
| 016166800 | Celikyay | PS600.21.00 | Dikmen |
| 6717700019 | TES |
| Number | Brand | Number | Brand |
|---|---|---|---|
| 42126923 | Iveco | 42126922 | Iveco |
