NS14.003.00 Leaf Spring for Hyundai HD 65/72/78

alt
alt
alt
alt
Description

69xØ34xØ27,80

NS14.003.00 Leaf Spring for Hyundai HD 65/72/78

Accessories
Material
$63.94
Add to cart
Available
Min. 50 pcs
Lead time 90 days
Placement
Rear
Type
Parabolic
Length (mm)
625-625
Section (mm)
70*1/10+5/11+2/12+1/11+1/10
Arc height (mm)
90/60
Weight (kg)
52.0000
Max Load (tons)
Comment
Part No Comment Type Weight (kg) Length (mm) Section (mm) Price
alt
NS14.003.01
Conventional 8.2500 625-625 70*10
Available
$10.53
alt
NS14.003.02
Conventional 7.8000 690-625 70*11
Available
$9.96
alt
NS14.003.03
Conventional 5.7500 515-515 70*11
Available
$7.34
alt
NS14.003.04
Conventional 4.5500 405-405 70*11
Available
$5.81
alt
NS14.003.05
Conventional 3.3000 320-320 70*11
Available
$4.21
alt
NS14.003.06
Conventional 2.0000 240-240 70*11
Available
$2.55
alt
NS14.003.31
Parabolic 6.2000 495-495 70*12
Available
$7.91
alt
NS14.003.32
Parabolic 6.2000 495-495 70*12
Available
$7.91
alt
NS14.003.33
Parabolic 5.3000 460-460 70*11
Available
$6.76
alt
NS14.003.34
Parabolic 0.7500 70-70 70*10
Available
$0.95
alt
NS14.003.01 Leaf Spring for Hyundai HD 65/72/78
Comment
Length (mm)
625-625
Type
Conventional
Section (mm)
Weight (kg)
8.2500
$10.53
Available
alt
NS14.003.02 Leaf Spring for Hyundai HD 65/72/78
Comment
Length (mm)
690-625
Type
Conventional
Section (mm)
Weight (kg)
7.8000
$9.96
Available
alt
NS14.003.03 Leaf Spring for Hyundai HD 65/72/78
Comment
Length (mm)
515-515
Type
Conventional
Section (mm)
Weight (kg)
5.7500
$7.34
Available
alt
NS14.003.04 Leaf Spring for Hyundai HD 65/72/78
Comment
Length (mm)
405-405
Type
Conventional
Section (mm)
Weight (kg)
4.5500
$5.81
Available
alt
NS14.003.05 Leaf Spring for Hyundai HD 65/72/78
Comment
Length (mm)
320-320
Type
Conventional
Section (mm)
Weight (kg)
3.3000
$4.21
Available
alt
NS14.003.06 Leaf Spring for Hyundai HD 65/72/78
Comment
Length (mm)
240-240
Type
Conventional
Section (mm)
Weight (kg)
2.0000
$2.55
Available
alt
NS14.003.31 Leaf Spring for Hyundai HD 65/72/78
Comment
Length (mm)
495-495
Type
Parabolic
Section (mm)
Weight (kg)
6.2000
$7.91
Available
alt
NS14.003.32 Leaf Spring for Hyundai HD 65/72/78
Comment
Length (mm)
495-495
Type
Parabolic
Section (mm)
Weight (kg)
6.2000
$7.91
Available
alt
NS14.003.33 Leaf Spring for Hyundai HD 65/72/78
Comment
Length (mm)
460-460
Type
Parabolic
Section (mm)
Weight (kg)
5.3000
$6.76
Available
alt
NS14.003.34 Leaf Spring for Hyundai HD 65/72/78
Comment
Length (mm)
70-70
Type
Parabolic
Section (mm)
Weight (kg)
0.7500
$0.95
Available
Name Price
alt
NS10256 Steel Bush for Hyundai HD (d27.8xd34x69)
Available
$0.00
alt
NS10256 Steel Bush for Hyundai HD (d27.8xd34x69)
$0.00
Available
Number Brand Number Brand
KS900.64.00 Dikmen 3010171-00 Spring Tech
Number Brand Number Brand
55100-5H500 Hyundai
